Jaw Crusher


Jaw crusher is one of the most popular stone-crushing equipment in the world and it is ideally suitable for primary and secondary crushing.
Get Quote Get More Help
Features:
    • Low operating costs, reliable quality can be guaranteed for many years without repair.
    • Good particle size, the crushing cavity and jaw plate tooth have been designed specially.
    • Good performance, it is well suit for running in very poor working environment.

Features

Introduction Of Jaw Crusher

The jaw crusher is also called jaw crusher machine,primary crushers,primary jaw crusher or tiger mouth. The crushing cavity of the jaw crusher is made up of dynamic jaw board and static jaw board and finishes the crushing process by simulating the movement of animal jaws. Jaw crusher is widely used to crush medium sized granularity of different ores and bully materials in mining, metallurgy, building materials, highway, railway, water conservancy and chemical industries. The highest compressive strength of the crushed materials reaches 320Mpa.

Advantages Of Primary Jaw Crusher

1. Integrative full-set machine frame

2. Flexibility

3. Low material transportation fee

4. Direct and effective operation

5. Strong suitability and flexible configuration

6. Reliable performance and easy repair

Characteristics Of Jaw Crusher Machine

1. The jaw crusher machine solves the high running rate and little maintenance time problems caused by the low yield of the traditional limestone crushers.

2. The jaw crusher machine can break bulk limestone with the maximum grain diameter of 1000*1200mm, which solves the limestone supply tension problem meanwhile the bulk limestone is not available.

3. The two materials are mixing evenly, so the desulfuration limestone is added with increasing quantity as high as 60%, thus saving the raw materials cost.

4. The jaw crusher reduces the power consumption and the power for processing one ton of limestone decreases by 1-2KW/t. This will save 0.1 million RMB electric charge per year.

Working Principle Of Primary Crushers

The dynamic jaw moving from side to side is hung on the mandrel. When the eccentric shaft is turning, its connecting rod moves up and down, which also drives the two thrust plates to do the same movement. Then the dynamic jaw moves from side to side to realize crushing and unloading. The jaw crusher adopts crank link mechanism. Although the dynamic jaw bears great broken counter-force and the eccentric shaft and the connecting rod bears little stress, industrial enterprises usually make large sized machine and middle sized to crush hard materials. Additionally, every moving track of the dynamic jaw is an arc with the mandrel as its center. The circular arc radius equals the distance from the point to the axis with the upper arc being smaller and the lower arc bigger. The crushing efficiency of the jaw crusher is quite low and the crushing ratio is 3-6.

Parameter

Technical Parameters Of Jaw Crusher

Model
Feed opening
(mm)
Max.feeding size
(mm)
Adjusting range of discharge opening
(mm)
Processing capacity
(t/h)
Rotation speed of eccentric shaft
(r/min)
Motor power
(kw)
Total weight
(t)
Dimensions
(L×W×H)
(mm)
PE-150×250 150×250 125 10-40 1-3 250 5.5 0.8 720×660×850
PE-200×300 200×300 180 15-50 2-6 260 7.5 1.2 910×750×990
PE-200×350 200×350 180 18-70 3-10 260 11 1.5 1000×870×990
PE-250×400 250×400 210 20-60 5-20 300 15 2.8 1300×1090×1270
PE-400×600 400×600 340 40-100 16-60 275 30 7 1730×1730×1630
PE-500×750 500×750 425 50-100 40-110 275 55 12 1980×2080×1870
PE-600×750 600×750 500 150-200 80-240 275 55 15.8 2070×2000×1920
PE-600×900 600×900 500 65-160 50-180 250 55 17 2190×2206×2300
PE-750×1060 750×1060 630 80-140 110-320 250 110 29 2660×2430×2800
PE-800×1060 800×1060 640 130-190 130-330 250 110 29.8 2710×2430×2800
PE-830×1060 830×1060 650 160-220 150-336 250 110 30.7 2740×2430×2800
PE-870×1060 870×1060 660 200-260 190-336 250 110 31.5 2810×2430×2800
PE-900×1060 900×1060 685 230-290 230-390 250 110 33 2870×2420×2940
PE-900×1200 900×1200 750 95-165 220-450 200 110 52 3380×2870×3330
PE-1000×1200 1000×1200 850 195-265 315-500 200 110 55 3480×2876×3330
PE-1200×1500 1200×1500 1020 150-350 400-800 180 160-220 100.9 4200×3300×3500
PE-1500×1800 1500×1800 1200 220-350 500-1000 180 280-355 122 5160×3660×4248
PE-1600×2100 1600×2100 1500 300-400 1300-2200 160 350-380 150.6 6210×4013×4716
PEX-150×750 150×750 120 18-48 8-25 320 15 3.8 1200×1530×1060
PEX-250×750 250×750 210 25-60 13-35 330 30 5.5 1380×1750×1540
PEX-250×1000 250×1000 210 25-60 16-52 330 30 7 1560×1950×1390
PEX-250×1200 250×1200 210 25-60 20-61 330 37 9.7 2140×1660×1500
PEX-300×1300 300×1300 250 20-90 16-105 300 55 15.6 2720×1950×1600
