Cement Mill


Cement mill,also called cement miller,is used for grinding raw materials of cement in the cement grinding process.
Get Quote Get More Help
Features:
    • The cement mill has high grinding efficiency and large output.
    • The process is simple with small power consumption.
    • The cement mill has high adaptability.

Features

Introduction Of Cement Mill

Cement mill, also called cement miller, is used for grinding raw materials of cement in the cement grinding process. Cement mill is not only suitable for over-flow grinding, but applicable for cyclic closed-flow grinding together with powder collector.

Working Principle Of Cement Miller

This cement mill machine has two warehouses. The cement mill grinder runs along the outside gear. In the cement mill, the materials spirally and evenly enter the first warehouse along the cement mill input hollow axis. In the warehouse, there is a ladder scale board or ripple scale board. The steel balls of different specifications are installed in the scale board of the cement mill. When the barrel body rotates, centrifugal force is produced. At the same time, the steel balls are carried to a certain height and then fall to grind and strike the materials. After being ground coarsely in the first warehouse, the materials then enter the second warehouse of for further grinding. In the end, the powder will be discharged.

China Cement Mill

Henan Hongxing Mining Machinery Co., Ltd. is a large-scale manufacturer of China cement mill. Cement machinery has adopted powder concentrator to avoid the ash of coarse powder and the grinding head and the working environment of the cement plant have been greatly improved. In addition, materials go into the cement machine calcining warehouse and after the strict classification, they are discharged from the sieve, so there is no coarse clinker and other materials. Hongxing cement machinery has introduced internationally advanced technology and it has produced high quality equipment with preferential cement mill price.

Cement Mill Price

Lowest price points in the industry of cement mill,please call: +86-371-67833171

Parameter

Technical Parameters Of Cement Mill

Product specification
(m)
Milling form Transmission form Gear box Motor power
(kw)
Production capacity
(t/h)
Total weight
(t)
Model Speed reduction ratio
Φ1.83×7 Open flow Brim ZD60 4.5 245 6.5-8 43.8
Φ2.2×7.5 Circle flow Brim ZD70 5 380 8-10 64.8
Φ2.2×11 Open flow Central shaft D110 35.5 630 12-13 104.6
Φ2.2×13 Open flow Central shaft D110 35.5 630 16-18 114
Φ2.4×13 Open flow Central shaft D110 35.5 800 20-23 130.6
Φ2.6×13 Open flow Central shaft MFY100 19.5 1000 28-32 158
Φ3×9 Circle flow Brim D125 41.2 1000 28-36.5 167
Φ3×11 Circle flow Central shaft D140 42.8 1250 36-47 180
Φ3.2×13 Open flow Central shaft D140 36.5 1600 45-50 225
Φ3.5×13 Circle flow Brim JDX1000 5.84 2000 60-65 275
Φ3.8×13 Open flow Central shaft MFY250 16.5 2500 60-62 320
Φ4.2×13 Open flow Central shaft JQS3550 15.6 3530 85-87 380
Φ4.6×14 Circle flow Central shaft JSI160-C 14.6 4200 120-135 485
